LS 1200d Pro
$3,390.00
Unit price /
Unavailable
Specifications
CCT
5600K
CRI
≥ 96
TLCI
≥ 98
CQS
≥ 95
SSI (D56)
≥ 73
TM-30 RF (Average)
93
TM-30 RG (Average)
102
Beam Angle (No Accessories)
66°
Beam Angle BM1215 Bowens Mount Hyper Reflector (Narrow)
15°
Beam Angle BM1230 Bowens Mount Hyper Reflector (Medium)
30°
Beam Angle BM1245 Bowens Mount Hyper Reflector (Wide)
45°
F10 Fresnel
15° ~ 45°
Lumens
126,413 lm
Max Power Output
≤1,200W
Max Power Consumption
≤1,440W
Max Operating Current
15A Max
Operating Voltage (Power Supply)
100V~240V, 50Hz/60Hz
Operating Voltage (Battery) 3-Pin XLR (48V DC) - Half Output (720W / One Input)
Regulated 48V/15A
Operating Voltage (Battery) 3-Pin XLR (48V DC) - Full Output (1,440W / Two Inputs)
2x Regulated 48V/15A
DC Input
2x 48V 3-Pin XLR DC Inputs (720W Each)
Operating Temperature
-20°C ~ 45°C / -4°F ~ 113°F
Dimming
0-100%; Linear, Exponential, Logarithmic, S-Curve
Control Methods
On-board, Sidus Link App, DMX512, Art-net & sACN via etherCON, LumenRadio CRMX
Wireless Operating Range (Bluetooth)
≤80m
Wireless Operating Range (LumenRadio)
≤100m
Screen Type
LCD
Firmware Upgradeable
USB (FAT16/FAT32), Sidus Link
Cooling Method
Active Cooling
Head Cable
LS 1200 Series 7-Pin Weatherproof Head Cable (7.5m)
Max Head Cable Length
7.5m
Power Cable
Neutrik® powerCON TRUE1 TOP AC Cable for LS 1200 Series (6m)*
Accessory Mount
Bowens Mount
Tilt Angle
360°
Mounting
28mm / 1.125in (Junior Pin)
Carrying Case
Telescoping Handle, Wheels
Estimated LED Lifetime (L70)
50,000H
Est. Color Shift Over Lifetime (CCT)
2% (6,000H)
Est. Max Flicker-Free FPS
2,000 FPS
Certifications
CE, FCC, ROHS, KC, NCC, PSE, BIS
